Festool 203165 Hinge location cutter

The perfect joint. Now even more versatile. The new basic structure connectors and furniture connectors for the DOMINO DF 500 joining machine.
The new DOMINO basic structure connectors and furniture connectors enable stable yet flexible furniture designs that can be separated again. Because of their great versatility, they provide for a very large range of applications – from corner panel joints to centre panel joints to joints between a series of holes. For unique flexibility, speed and efficiency.

The clever DOMINO system enables very simple and precise positioning of joints, thereby rendering additional stops and positioning aids unnecessary. For working efficiently and quickly
The connectors' large tightening distance and long bolts make furniture assembly significantly easier. Cupboard assembly is therefore no problem, and you can do it easily on your own.
The flush-screwed fixture elements protect each furniture component from being scratched
Routing and cutting tolerances of up to 1.4 mm are compensated for without problems by the fixture
The new detachable DOMINO basic structure connectors and furniture connectors are perfectly suited for a panel thickness of 18 mm to 28 mm
15 mm hinge location cutter is required for drilling holes in the surface of the DOMINO D 8 mm joint fixture
Shaft mount: CENTROTEC
the drill bit is adapted to the Festool drill template (203164)

It could not be easier
There is no easier way of producing a detachable corner joint. The drill template – which can be used with an extraction system – specifies the exact position of the drilled hole and the correct drilling depth, therefore guaranteeing error-free work.

Perfectly aligned
The 15 mm hinge location cutter and the DOMINO drill template form an unbeatable team. With the aid of the drill template, correctly positioning the fixture hole is child's play.

Technical Data

Drill bit dia. 15 mm

Items included
depth stop
